VIS Boats are Premium Fully Electric Pontoon Boats

Designed for Clean All-Day Fun on the Water



Our purpose is to produce a Premier Pontoon Boat with Electric Propulsion for commercial sales. VIS Pontoons will deliver competitive onboard luxury and versatility while giving superior performance. The boats will be 18’ to 22’ Tri-toon Pontoons with a top end speed of 30+ miles per hour with exclusive electric torque acceleration. Runtime on the water will not inhibit the all-day fun pontoon owners should expect. VIS boats will provide owners with 8+ hours of cruising around on a single charge, and can be fully charged overnight, or in several hours at a quick charge station.



Electric Propulsion

  •       384VDC Electric Brushless Permanent Magnet Motor, 95% Peak Efficiency, Operating Speed 0-7000rpm, 320Nm of  Torque, 135kW          Maximum power output
  •       52kWh capacity Lithium-Ion Battery Pack, 80% Useable Energy Storage, >10,000 Charging cycles
  •       Integrated Digital DC/DC converter
  •       Digital AC/DC charger, Plug-in Charging from 110AC or 240AC
  •       Computer controlled Battery Management System
  •       Electric vehicle interface control software, Electronic 3 stage power mode controls
  •       All components managed and controlled by exclusive VIS Propulsion management system
  •       CAN bus communications protocol
  •       Proprietary lower-end dual gearing and efficiency matched 14” 3blade Stainless Propeller
  •       VIS exclusive 50/50 Glycol – Water Battery and Motor cooling system

Structure & Furniture

  •       Recycled Aluminum D-Channel Framing on 16” Centering for stability
  •       25” Diameter Recycled Aluminum Tubes with Lifting strakes inside of outer tubes and both sides of the center tube
  •       Recycled Plastic Decking bolted to frame and Sustainably Produced  oven vinyl flooring
  •       Powder coated recycled aluminum railings and Bimini top
  •       Recycled corrugated aluminum playpen sheeting
  •       LED interior lighting, Tube accent lighting, Docking lights, and USCG navigation light

Helm

  •       Fiberglass and aluminum framing, trimmed in premium sustainably created upholstery and accented brushed aluminum trims
  •       Three 7" LCD Touch Screen Displays and lighted touch switch /control panels
  •       JL Audio two section audio system with six premium speakers and lighted accents, 10" JL Subwoofer and Dual JL Audio amplifiers              for the best sound experience
  •       Down and Front Sonar with fish finder
  •       GPS mapping and tracking
  •       Rear ski Camera display
  •       Battery and motor intuitive digital displays give information and interface control for Battery Temp, Motor Temp, Power Available,            Real-time Runtimes, Motor power input, Speed, RPM, Battery Charge % and Throttle modes
